Size (HxWxD):

42x37x12 ±0.5 mm / 1.65×1.46×0.66 ±0.02 in

Power supply:

12/24 VDC

Power consumption:

< 1.2 W

Max. control voltage:

24 VDC

Max. control current:

4 A per channel (10 A total)

PWM frequency

22 kHz

Power and energy meters:

Power measurement

No load threshold:

0.5 VA per channel

Wi-Fi

802.11 b/g/n

Range:

Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions)

Bluetooth

4.2

Range:

Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions)
